Kiltel tunnel kiln supervisory system

Control panel for 10-burner pulsed periodic kiln being installed.

Tunnel kiln supervisory system internals

Periodic kiln pulsed burner setup with FSU.

Pulsed combustion retrofit

Pulsed combustion shuttle kiln, initial burner tune-up.

Main screen design for a vacuum furnace.

Tunnel kiln rebuild with pulsed combustion.

"License Plate" PV display screen without added graphics.

Replacement of an obsolete PLC system with a Kiltel data panel.

Vacuum furnace control.

Yokagawa loop controllers and Kiltel data panel mounted on the enclosure door.

Screen display showing a tunnel kiln profile plus a multi-variable trend plot.

Periodic kiln screen showing a run-progress plot together with the Stop/Hold/Resume dialog.

Tunnel kiln profile and multi-variable trend plot.
